Introduction:

* Apply to aluminum and PVC profiles for 45 degree cutting

* Imported linear bearing guide results in highly precise processing.

*Super big worktable enables to cut four profiles in one time.

* Two heads can work independently or together.

* Working with a single head mitre saw, highly improves the efficiency.

Technical Parameter:

Model                                                LJZ2-450×3600

Input voltage                                    380V/50Hz

Input power                                      3.0Kw

Air pressure                                     0.5~0.8MPa

Air consumption                              220L/min

Motor rotation speed                      2800r/min

Cutting length                                   310~3600mm

Cutting width                                    10~320mm

Cutting height                                   10~100mm

Cutting angle                                    45°

Saw feeding speed 0~3m/min

Saw blade standard φ450×4×φ30×Z120

Overall dimension 4800×1800×1500mm
