Introduction:

* Used for aluminum profile end processing, and suitable for various profiles.

* Process multi-piece profiles in one clamp, high efficiency.

* Convenient tool adjustment, can meet different processing requirement.

* It can complete angular milling, one group of miller can be adjusted between angles

 ±45°.

* Airdraulic damping cylinder adopted in feeding system, gives stable velocity.

*It has features of easy operation, reliable performance, advanced technique and

convenient maintenance.

Technical Parameter:

Model                                           LXDB-250W

Input voltage                               380V/50Hz

Input power                                 4×2.2kw

Air pressure                                0.5~0.8MPa

Air consumption                        180L/min

Motor rotation speed                 2800r/min

Worktable range                         0~1400mm

Max processing hole                 40mm

Milling cutter diameter               φ250mm /φ300mm

Adjustment range                       0~85mm

Overall dimension                      3300×1200×1700mm
